3 axles flour transporting tank trailer - 副本

Product Item：GT0103GXH

Payload(Cbm):25-100

Tare weight (kgs):9500

Material:Carbon Steel/alloy

Axles :13 ton(16ton,20ton) capacity

Description

QINGDAO SHIYUN TRAILER CO.,LD ,is a professional China Trailer manufacturer with brand “girder trailer”.For transporting low density power material ,we have bulk cement tank trailer and flour tank trailer.Both of them are silo type.

3 axles flour tank semi trailer:

Features:

1.Can design different volume of tank body.Volume from 20cbm to 100cbm.

2.Tank material can be carbon steel and aluminum

3.The shape can be V shape,W shape or tapered shape.

4.Axles number can be 1,2,3,4 axles or superlink axles for transporting different weight power material.

5.Man hole 500mm

6.Discharge valve and tube can be 4’’ or other size optional

7.can be outfit engine and air compressor for different volume.

Parameters:

Model	GT0103GMF
Size	1158025003800 (mm) (Other dimensions optional)
Tank body	5mm with end plate 6mm
Axles	2/3/4 * 13ton capacity (Brand optional)
Suspension	Mechanical suspension with leaf springs (Air suspension/bogie optional)
Tire	12R22.5 315/80R22.5 8/12/16pcs (Other size optional)
Rim	9.00-22.5 8/12/16pcs (Other size optional)
King pin	2’’/3.5’’ bolt type
Landing gear	28 Ton two speed
Braking system	Double air chamber ,brake valve,40L air tanks ;ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
