liquefied petroleum gas tanker semi trailer,LPG tank trailer

Product Item：GT0301GYQ

Suspension:Mechanical suspension (Air suspension optional)

Material ：Q370R(Normalizing）

Size ：12000*2500*3990 (mm) (Other dimensions optional)

Axles ：3 * 13ton capacity (Brand optional)

Description

QINGDAO SHIYUN TRAILER CO.,LD ,is a professional China Trailer manufacturer with brand “girder trailer”.Tank trailers are used to transport liquids and gas in large volumes.The trailers came in different models because of the wide variety of liquefied loads.

Liquid tank trailer
Type	Model	Usage
Oil tank semi trailer	GT0301GYY	Gasoline,diesel oil,kerosene,jet fuel
Bitumen/asphalt tank trailer	GT0201GLY	Tar,Bitumen ,asphalt
Chemical liquid tank trailer	GT0301GHY	Acids ,Alkalies,Hydrogen peroxide,ammonium hydroxide
Flammable liquid tank trailer	GT0301GRY	Crude oil, pentane, petroleum ether,alcohol
Liquid food tank trailer	GT0301GYS	Edible oil,beer,milk,water,juice,ice cream,sugar water
Pressure vessel
Type	Model	Usage
liquefied gas tank trailer	GT0301GYQ	Propylene,propane,butane,butadiene,liquid ammonia ,liquefied petroleum gas(LPG)
Cryogenic liquid tank trailer	GT0301GDY	Liquefied natural gas(LNG)
Compressed Natural Gas trailer	GT0301GRQ	Compressed Natural Gas(CNG)

liquefied petroleum gas tanker semi trailer,LPG tank trailer :

Parameters:

Model	GT0301GYQ
Material	Q370R(Normalizing）
Usage	Liquefied Gas
Size	1200025003990 (mm) (Other dimensions optional)
Work temperature	-20~50℃
Work pressure	≤1.61 Mpa
Capacity	40-65 m³
Emergency valve	Manual Gas phase DN25 and liquid phase DN50
Safety valve	Interior and full lift 2.5Mpa size 68
Level gauge	Float 50~2478
L.U.S	Quick tie-in Gas phase DN25 and liquid phase DN50
Axles	3 * 13ton capacity (Brand optional)
Suspension	Mechanical suspension (Air suspension optional)
Leaf spring	10pcs
Tire	12R22.5 315/80R22.5 12pcs (Other size optional)
Rim	9.00-22.5 12pcs (Other size optional)
King pin	2’’/3.5’’ bolt type
Landing gear	28 Ton two speed
Braking system	Double air chamber ,brake valve,40L air tanks ;ABS optional
Electrical	LED light , 7 ways ,24V
Painting	Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting
